SWIVEL - Electroless nickel plated steel 90◦ full-flow NPT swivel for simple seal maintenance and fast and easy hose installation. No need to remove the reel from its mount.
CARTRIDGE MOTOR - Lubricated and enclosed cartridge-style motor is easily removable for safe and convenient maintenance.
CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
BOX-STYLE DESIGN - Sturdy box-style, reinforced steel frame design provides maximum strenght and stability.
STEEL ROLLERS - Heavy duty 1" stainless steel pinch-proof rollers.
OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable solid rubber hose stop,fuel dispensing hose, and sturdy permanently lubricated precision bearings.
SP Series
Brand Name
Coxreels
Assembled Depth (in)
30.375
Assembled Weight (lbs)
193
Assembled Width (in)
21
Color
Blue
Country of Origin
United States
globalTradeItemNumber (GTIN)
00674255821460
Height (in)
28.5
Maximum Pressure Rating (psi)
300
Package Contents
Spring driven reel, pvc hose, hose stop
Package Depth
22
Package Height
26
Package Weight
193
Reel Drive / Return Type
Spring Loaded Return
