DESCRIPTION
Eagle Compressor 20 gallon Portable Electric Air Compressor
Eagle P3120H1-CC 20 Gallon tank 3.0 HP air compressor. Thermally protected 3 HP and 115 volt electric motor- CSA/US approved. Oil lube compressor delivers 5.6 CFM 90. 135 Max PSI. Lever type tank drain. Easy view oil sight gauge. Metal air filers with “auto drop” feature. Outlet control regulator with quick connectors. Efficient heat removal from the fly wheel for cooler running and longer life. Sturdy metal belt guard. Rugged tires includes intrigued wheel kit for easy mobility.
FEATURES
SPECIFICATIONS
Brand Name
Eagle Compressor
Air Compressor Pump Design
Oil Lubricated
Amperage (A)
12
Assembled Weight (lbs)
170
California Proposition 65 Warning Required
Yes
Compressor Design
Wheelbarrow/Wheeled
Country of Origin
United States
CSA Certified
Yes
ETL Listed
Yes
globalTradeItemNumber (GTIN)
00777589003578
Height (in)
30
Horsepower (hp)
3
Internal Supplier Part #
P3120H1-CC
Internet Product Code (IPC)
8A3C739DC2C
Manufacturer Warranty
TWELVE (12) MONTHS FROM DATE OF START
Maximum Pressure Rating (psi)
135
Operating Position
Horizontal
Package Contents
20 gallon Portable Electric Air Compressor
Package Depth
42
Package Height
33
Package Weight
170
Package Weight (lbs)
170
Tank Capacity (gal)
20
Tank Configuration
Single
Tank Material
Steel
Tank Pressure Gauge
Yes
UL Listed
Yes
UPC
777589003578
Voltage
115
Weight (lbs)
160
Wheeled
Yes
TWELVE (12) MONTHS FROM DATE OF START
