DESCRIPTION
Campbell Hausfeld Air Compressor 30 Gallon
The Campbell Hausfeld 30-gallon, 13 hp, two-stage air compressor (CE7003) with Honda engine is perfect for a work truck or worksite location without electric power. This air compressor has a high air flow of 26.1 CFM @ 90 PSI to power multiple, high-demand air tools. It features a long-life, cast-iron, two-stage pump that’s designed to deliver more than 15,000 hours of operation. The pump head and valve plate feature an advanced design with Viton(r) high-temperature O-rings for superior high-pressure sealing when compared to paper gaskets. For smooth, low-vibration operation, the crankshaft is fabricated of ductile iron and optimally balanced.
FEATURES
SPECIFICATIONS
Brand Name
Campbell Hausfeld
Assembled Weight (lbs)
465
California Proposition 65 Warning Required
Yes
Compressor Design
Horizontal (Stationary)
Country of Origin
China
CSA Certified
Yes
ETL Listed
No
Height (in)
54
Horsepower (hp)
13.00
Internal Supplier Part #
CE7003
Manufacturer Warranty
3 year limited
Maximum Pressure Rating (psi)
175
Operating Position
Horizontal
Package Contents
Air Compressor 30 Gallon
Package Depth
25
Package Height
54
Package Weight
465
Start Type
Electric
Tank Capacity (gal)
30
Tank Configuration
Single
Tank Material
cast iron
Tank Pressure Gauge
Yes
UL Listed
Yes
UPC
045564627249
Weight (lbs)
465
Wheeled
No
3 year limited
